Classification of Well Drilling Rig

2023/03/20 09:34

Generally, there are three sorts of rotary drilling rig, influence drilling rig and composite drilling rig.


Rotary drill
The gap is fashioned by using breaking the rock stratum by way of the rotary movement of the drilling tool. It often consists of giant and small pot cone drills, superb and reverse circulation rotary desk drills, and hydraulic strength head drills machine, down-the-hole vibration rotary drill, etc. A easy rotary drill has solely a drilling device, whilst a well-structured rotary drill consists of a drilling gadget and a circulating nicely flushing device. The drilling device of rotary nicely drilling rig consists of drill pipe and drill bit. The nominal diameters of frequently used drill pipes are 60, 73, 89 and 114 mm. The drill bits are divided into two types: full drill bit and annular drill bit. Large and small pot cones use their pot cone drilling equipment to rotate and reduce the soil layer. According to the measurement of the drilling tool, they are known as huge pot cone and small pot cone, which can be pushed by means of manpower or power. The reduce soil scraps fall into the pot and are lifted to the floor for unloading. Its shape is easy and its work effectivity is low. It can solely be used in regular soil layers or layers with a diameter of no extra than 10 cm and a content material of no extra than 50%. The gap diameter of the small pot cone is 0.55m, and the drilling depth is 80-100m; The gap diameter of the massive pot cone is 1.1 meters, and the drilling depth is 30-40 meters. The rotary drilling rig (Fig. 1) is many times used for the rotary drilling rig of effective and reverse circulation mud washing, that is, the rotary drilling rig of advantageous circulation mud washing consists of tower, winch, rotary table, drilling tool, mud pump, swivel and motor. During operation, the strength computer drives the rotary desk thru the transmission device, and the lively drill pipe drives the drill bit to rotate and wreck the rock stratum at a pace of 30~90 rpm. After being pumped and pressurized by means of the mud pump, the mud is pressed into the hole drill pipe via the faucet above the drill pipe, flows downward into the drill bit, and is ejected from the nozzle to cool and lubricate the drill bit; The cuttings at the backside of the nicely are introduced out of the wellhead thru the annular channel backyard the drill pipe. After settling in the sedimentation tank, the mud flows again to the mud pool for recycling. The drilling approach and shape of the reverse circulation mud washing rotary drilling rig are essentially the equal as the above, however the mud circulation mode is opposite: the mud flows into the backside of the properly from the wellhead after settling in the sedimentation tank, and the mud carrying rock cuttings is pumped out of the nicely thru the drill pipe cavity via the bit nozzle by way of the sand pump, and then returns to the sedimentation tank. This technique is known as pumping reverse circulation. Water pump can additionally be used to inject pressurized water from the backside of the properly into the internal cavity of the drill pipe via the nozzle to structure an upward waft carrying rock cuttings, which is referred to as jet reverse circulation. The drill can shape a excessive rising speed in the drill pipe, and has a sturdy potential to discharge rock cuttings and pebbles, so the drilling pace is faster. It is relevant to soil layer, usual sand layer and loose stratum with pebble diameter smaller than the internal diameter of drill pipe. The internal diameter of drill pipe used is exceedingly large, commonly 150~200mm, and the most can attain 300mm. However, due to the quandary of the pumping or pumping ability of the pump, the drilling depth is commonly much less than one hundred fifty meters, and the cuttings elimination effectivity is greater when the nicely depth is much less than 50 meters. The rotary desk drilling rig for stress fuel nicely flushing makes use of air compressor as an alternative of mud pump and compressed air as an alternative of mud for nicely flushing. Generally, reverse circulation is adopted, additionally recognized as gas-lift reverse circulation (Figure 2). That is, compressed air is despatched to the gas-water mixing chamber in the nicely thru the gasoline grant pipeline to combine with the water drift in the drill pipe to structure aerated water waft with a unique gravity of much less than 1. Under the gravity of the annular water column round the drill pipe, the aerated water float in the drill pipe with rock cuttings always rises and flows out of the properly into the sedimentation tank, and the settled water flows lower back into the nicely through gravity. When the nicely depth is giant (more than 50 meters), the cuttings elimination potential of the drilling rig is larger than that of the drilling rig with pumping or jet reverse circulation, so it is appropriate for the scenario of massive nicely depth, dry areas with water shortage, and frozen soil layer in bloodless zone.


Some rotary drilling rigs are geared up with mud pump and air compressor at the identical time, and exclusive properly flushing strategies can be chosen in accordance to the situation.

Hydraulic strength head drill is a form of rotary drill. It is pushed by using the hydraulic motor thru the reducer, and the rotary desk and faucet on the rotary desk drill are changed by means of the strength head shifting up and down alongside the tower to power the drill pipe and drill bit to rotate and reduce the rock stratum. Large-diameter water wells can be drilled with a massive drill bit with a diameter of up to 1 meter, which is characterised with the aid of speedy drilling speed, convenient loading and unloading of the drilling device and reducing of the nicely pipe, no want to raise the drilling device when lengthening the drill pipe, and a sequence of factors such as winch, lifting pulley, rotary table, faucet, and kelly are certainly avoided. Down-the-hole vibration rotary drill is a sort of rotary drill that drills rock stratum by using combining vibration and rotary motion. The drilling device is composed of drill bit, vibrator, vibration damper and information barrel (Fig. 3). The interesting pressure generated with the aid of the vibrator makes the total drilling device cross in a conical swing. The drill bit is sleeved on the outdoor of the vibrator shell via the friction ring. On the one hand, it vibrates with the vibrator in a horizontal round vibration with a frequency of about a thousand rpm and an amplitude of about 9 mm; On the different hand, it makes a low-speed rotation motion of 3~12 rpm round the vibrator axis to ruin the rock stratum, whilst the drill pipe does now not rotate, and makes use of the vibration damper to keep away from transmitting the vibration to the drill pipe. The compressed air reverse circulation technique is used to wash the well, so that the cuttings are discharged out of the properly via the conduit and drill pipe cavity placed in the middle of the vibrator. This drill has easy shape and excessive drilling efficiency. The gap diameter is about 600mm, and the drilling depth can attain 150m.

Classification of Well Drilling Rig
